Introduction

A lot of rigid logical connections have to be made in railroading. E.g. there are switches and there might be lanterns along the track to show the state of the switch. Also there might be signals to interact with the trains and then their semaphores to show the state of the logical signal. Another application is a sensor in the track that registers a wheelset rolling over it. Yet another application is to play sounds on certain events inside the railroading system; e.g. a rolling stock starts rolling and that triggers a looped sound to play that would be stopped again when the rolling stock stops rolling.

A Plug gets inserted into a Jack. Then it would receive the Jack's pulses. A Plug is very specific: it triggers one action and that action only; albeit this action might pulse other Jacks in turn.

To foreward the action of a Sensor a Plug needs to be inserted into the Sensor's Jack. The Plug then would Pulse the action it was created for.

A Word Of Warning

A word of warning is appropriate at this point. Even if we provide logical elements like counters and timers and all these form a turing-complete system, it is very advisable to keep the connection patterns simple and don't try tricks, because there are no tools for debugging or testing a complex system of Plugs N' Jacks connected elements. It is exclusively meant to tie simple elements together in a simple way, or to build logical blocks like a barrier that would close while some sensors that detect wheelsets would count a counter up and down, and that barrier would open if the counter becomes zero again.
